PV-R01 — Bearing Isolator
Non-contact bearing protection that keeps contamination out and lubricant in. Tell us your equipment and operating conditions and we confirm the fit before quoting.
PV-R01 • Engineering Reference
Overview
Bearing Isolator in the rotary and support systems family. Non-contact bearing protection that keeps contamination out and lubricant in. The figures on this page are the standard published range for the series — final face materials, elastomers and working length are set from your application data.
Specifications
| Model | PV-R01 |
|---|---|
| Type | Bearing Isolator |
| Family | Rotary and support systems |
| Series | — |
Materials
| Seal faces | Not specified for this item — tell us and we confirm it |
|---|---|
| Secondary seals | Viton (standard) |
| Metal components | Bronze rotor and stator |
Operating limits
| Shaft diameter | 10 – 200 mm |
|---|---|
| Temperature | -40 to +200°C |
| Notes | Axial movement ±0.2 mm, radial ±0.4 mm |
Standard published range for this series. We confirm the exact limit for your equipment in technical review.
Design and characteristics
- Rotor and stator are unitized so they can't separate
- No lubrication or special shaft finish required
- Vapor-blocking labyrinth reduces friction, heat and wear
Applications
Drawings and downloads
| Dimensional drawing | Available once your order is confirmed |
|---|---|
| Datasheet (PDF) | Datasheet (PDF) PDF, opens in a new tab |
Cross-reference
No verified cross-references to other brands are published for PV-R01 yet. Send the manufacturer and part number of your existing seal and we look for a potential replacement, then verify it in technical review.
