PV-F09 — Diaphragm
Flexible rubber diaphragms that block transfer of liquid or gas between two chambers. Tell us your equipment and operating conditions and we confirm the fit before quoting.
PV-F09 • Engineering Reference
Overview
Diaphragm in the specialty sealing family. Flexible rubber diaphragms that block transfer of liquid or gas between two chambers. The figures on this page are the standard published range for the series — final face materials, elastomers and working length are set from your application data.
Specifications
| Model | PV-F09 |
|---|---|
| Type | Diaphragm |
| Family | Specialty sealing |
| Series | — |
Materials
| Seal faces | Not specified for this item — tell us and we confirm it |
|---|---|
| Secondary seals | Not specified for this item |
| Metal components | NBR, Buna, EPDM, Viton, HNBR, silicone, fluorosilicone, polyurethane/SBR, neoprene, ACM, AEM |
Operating limits
| Range | Not specified for this item — tell us and we confirm it |
|---|
Standard published range for this series. We confirm the exact limit for your equipment in technical review.
Design and characteristics
- Molded to RMA A2 precision tolerances
Applications
Drawings and downloads
| Dimensional drawing | Available once your order is confirmed |
|---|---|
| Datasheet (PDF) | Datasheet (PDF) PDF, opens in a new tab |
Cross-reference
No verified cross-references to other brands are published for PV-F09 yet. Send the manufacturer and part number of your existing seal and we look for a potential replacement, then verify it in technical review.
